Victron Energy SmartSolar MPPT 150/35 regulator punjenja solarni

Victron Energy SmartSolar MPPT 150/35 regulator punjenja solarni

SCC115035210
Max PV 150V
35A
regulator punjenja za solare
12V, 24V, 48V
za Lead/Acid, AGM, GEL, Lithium (LifePO4)
130x186x70 mm
1,25kg

CIJENA:

359,10 €

Šifra proizvoda: SCC115035210

Komada

Trenutno nedostupno

Pošaljite upit Košarica

Victron Energy SmartSolar MPPT 150/35 regulator punjenja solarni

Part Nr. SCC115035210

SmartSolar MPPT solarni regulator punjenja osigurava najbolju moguću žetvu energije, bez obzira na vremenske prilike. Djeluje tako da osigurava da se sva energija uzima iz vaših solarnih panela i pohranjuje u vaše baterije, te inteligentno pretvara energiju tako da se vaša baterija napuni u najkraćem mogućem vremenu. Struja punjenja 35 A / Max. PV napon otvorenog kruga 150 V.

SmartSolar maksimizira žetvu energije i inteligentno je preusmjerava tako da vaša baterija bude potpuno napunjena u najkraćem mogućem vremenu. Djeluje tako da se sva energija uzima iz vaših solarnih panela i pohranjuje u vašim baterijama. Ovo je posebno korisno za oblačnih dana kada se intenzitet svjetlosti stalno mijenja. SmartSolar automatski detektira napon akumulatora i prikladan je za širok raspon napona akumulatora. Kontroler također ima programibilni algoritam punjenja, interni temperaturni senzor, VE.Direct vezu za povezivanje s drugim Victron uređajima ili računalom te Bluetooth.

EAN 8719076040187
Model no. SCC115035210
Description VICTRON - SmartSolar MPPT 150/35 solar charge controller
Solar regulator type MPPT
Charging outputs 1
Nominal Power @ 12 V 500 W
Operating voltage 12 V, 24 V, 48 V
Battery type Lead/Acid, AGM, GEL, Lithium (LifePO4)

Tehničke karakteristike

Victron Energy SmartSolar MPPT 150/35 regulator punjenja solarni

Technical data

Battery voltage	12/24/48 V
Rated charge current	35 A
Nominal PV power	12 V: 500 W 24 V: 1000 W 48 V: 2000 W
Maximum open circuit PV voltage	150 V
Operating temperature	-30 to +60 °C
Maximum efficiency	98%
Self-consumption	12 V: 20 mA 24 V: 15 mA 48 V: 10 mA
Charge voltage 'absorption'	14.4 V / 28.8 V / 57.6 V
Charge voltage 'float'	13.8 V / 27.6 V / 55.2 V
Charge algorithm	Multistage, adaptive
Protection	Reverse polarity on battery (fuse) PV reverse polarity Output short circuit Over temperature
Power terminals	16 mm²
Protection category	IP43 (electronic components) IP22 (connection area)
Dimensions (h x w x d)	130 x 186 x 70 mm
Weight:	1.25 kg
Standards	EN/IEC 62109-1, UL 1741, CSA C22.2

Dodatne specifikacije

MPPT 150/35 Specifications

SKU	VIC.SCC115035210
Model #	SCC115035210

Brand	Victron Energy

Dodatne specifikacije

MPPT 150/35

MPPT controllers operate solar panels at their Maximum Power Point improving efficiency up to 30% by adjusting input voltage to harvest the maximum power from the solar panels. It then manages this power to supply the varying voltage requirement of the battery plus load.

The MPPT senses when to adjust the output that it is being sent to the battery and will shut down for a few microseconds, calculate and make relevant adjustments. The principle of MPPT is to extract the maximum possible power from a solar panel by setting the most efficient combination of voltage and current - maximum power point.

The Victron MPPT SmartSolar support Advanced Maximum Power Point Detection. Unlike the conventional MPPTs which tend to lock to a local MPP when shady conditions occur, [which may not be the optimum MPP], Advance Maximum Power Point Detection will harvest maximin energy by locking to the optimum MPP.

Internal temperature sensor provides additional electronic protection

Over-temperature protection and power derating when temperature is high.
PV short circuit and PV reverse polarity protection.
PV reverse current protection.

Other features:

With no cooling fan the maximum efficiency exceeds 98%.
Flexible charge algorithm provides functionality for fully programmable charge algorithm, and eight preprogrammed algorithms, selectable with a rotary switch

Built-in Bluetooth along with the VictronConnect App provides easy access to the extensive range of functions available on your solar charge controller such as:

Solar Gauge – Realtime power output
Battery Voltage
Battery Current
Battery State
History Analysis
Various Settings

Victron MPPT model names explained

MPPT 100/30, the first number is the maximum PV open circuit voltage. The second number, 30, is the maximum charge current.
